Mahindra EarthMaster SX IV – Strength that Works Smarter.

Engineered for performance and designed to endure, the Mahindra EarthMaster SX IV backhoe loader blends intelligent engineering with raw power. With a BS IV-compliant engine, robust hydraulics, and efficient material handling capabilities, this model is built for contractors who demand more from every machine. It’s not just a backhoe—it’s a productivity powerhouse ready for the toughest terrains and tightest timelines.

---

Key Specifications

• Engine Power: 74 HP

• Max Operating Weight: 7,584 kg

• Loader Bucket Capacity: 1.1 m³

• Backhoe Bucket Capacity: 2.6 m³

• Max Digging Depth: 4,959 mm

• Max Lift Capacity: 3,428 kg

• Hydraulic System Flow: 117 L/min

• Fuel Tank Capacity: 140 L

---

Engine & Powertrain

The Mahindra EarthMaster SX IV is powered by the VNEF 3.5 L Turbocharged Intercooled diesel engine, designed for high efficiency, torque-rich performance, and compliance with BS IV emissions standards.

• Engine Model: VNEF 3.5 L Turbocharged Intercooled

• Displacement: 3,532 cc

• Gross Power: 74 HP

• Max Torque: 345 Nm

• Emissions Compliance: BS IV

• Transmission: 4-speed manual (4 forward, 4 reverse)

• Drive Type: Rear wheel drive with rigid rear axle and oscillating front axle

---

Hydraulic System

A powerful and efficient hydraulic system lies at the core of the SX IV’s performance. Optimized for fast cycle times and precise movements, it provides the responsiveness needed for high-demand applications.

• System Type: Open Centre, 25 MPa (250 bar)

• Pump Type: Fixed Displacement Gear Pump

• Hydraulic Flow Rate: 117 L/min

• Hydraulic System Capacity: 100 L

• Hydraulic Oil Replacement Volume: ~50 L

---

Loader Performance

The front loader is crafted for productivity—balancing breakout force with material capacity. Whether you’re moving sand, gravel, or construction debris, the SX IV handles it with ease.

• Loader Bucket Capacity: 1.1 m³

• Dump Height: 2,708 mm

• Load Over Height: 3,253 mm

• Reach at Ground: 1,350 mm

• Reach at Full Height: 1,115 mm

• Bucket Breakout Force: 6,243 kg

• Loader Arm Breakout Force: 5,594 kg

• Max Lifting Capacity: 3,428 kg

---

Backhoe Arm Performance

Digging deeper, reaching farther, and working smarter—the SX IV’s backhoe attachment is ideal for trenching, drainage, foundation prep, and more.

• Backhoe Bucket Capacity: 2.6 m³

• Max Dig Depth: 4,959 mm

• Reach (Ground to Swing Center): 5,794 mm

• Reach at Full Height (Slew Center): 2,774 mm

• Max Load Over Height: 4,131 mm

• Max Working Height: 6,043 mm

• Max Lifting Capacity: 3,428 kg

• Swing Arc: 180°

---

Chassis, Axles & Suspension

The SX IV’s rugged build is complemented by its durable axle setup, designed for stable movement and long-term reliability, even under heavy-duty use.

• Rear Axle: Rigidly mounted, outbound planetary final drives, short drive shaft

• Front Axle: Centrally pivoted, non-driven, unbalanced axle with 16° oscillation and remote greasing for easy maintenance

• Minimum Ground Clearance: ~400 mm

• Wheelbase: ~2,130 mm (approx.)

---

Steering & Control

• Steering Type: Hydraulic Power Steering

• Turning Radius: Tight turning for better maneuverability in restricted spaces

• Controls: Ergonomic dual lever loader/backhoe controls

---

Braking System

• Service Brakes: Hydraulically actuated, oil-immersed multi-disc brakes—maintenance-free, rear axle

• Parking Brake: Hand-operated, mechanically actuated caliper-type brake

---

Cabin & Operator Comfort

Operator efficiency starts with a better work environment. The SX IV comes with a thoughtfully designed cab that promotes productivity through comfort.

• Cabin Design: Weather-resistant cabin with clear visibility

• Controls: Intuitive layout, dual levers

• Seating: Adjustable suspension seat

• Dash Panel: Functional layout with diagnostic display

• Lighting: High-intensity work lamps for night jobs

---

Service Capacities

• Engine Oil: 13.7 L

• Transmission Oil: 19.2 L

• Rear Axle Oil: 17.1 L

• Coolant: 17 L

• Fuel Tank: 140 L

• Hydraulic System Oil: 100 L

---

Best Fit Applications

The Mahindra EarthMaster SX IV is suitable for:

• Road construction & infrastructure

• Building foundations & trenching

• Rural development projects

• Urban utility work & landscaping

• Material transport & loadout tasks

---

Why Choose Mahindra EarthMaster SX IV from Ekin Traktors

At Ekin Traktors, we don’t just sell machines—we supply solutions. The EarthMaster SX IV represents our commitment to power, reliability, and value. When you purchase through us, you gain access to:

• 🛠️ Expert-backed pre-shipping inspections

• 🚛 Cross-border logistics and dealer support

• 🧰 Aftermarket service, spares, and advisory

• 💼 Flexible finance and fleet plans

• 🌎 Availability across USA, Australia, and Europe
