Hamm HW90/10 Roller

Hamm HW90/10 Pneumatic Tyre Roller
Available through Ekin Traktors

The Hamm HW90/10 is a compact, durable pneumatic tyre roller designed for versatile asphalt and base layer compaction. With its balanced weight distribution, even tyre contact pressure, and adjustable ballast options, the HW90/10 delivers reliable surface sealing and high-quality finish compaction. Now available through Ekin Traktors, this machine offers an efficient solution for urban infrastructure, road repair, and light-to-medium compaction jobs.

Simple, robust, and dependable — the HW90/10 combines classic engineering with operator-focused functionality.

---

Key Specifications

• Operating Weight: Approx. 9,000 – 10,000 Kg (adjustable with ballast)

• Tyres: 4 front + 4 rear pneumatic tyres

• Working Width: Approx. 1,800 – 2,000 mm

• Engine Model: Deutz F4L912 or equivalent industrial diesel

• Power Output: Approx. 55 – 65 HP

• Fuel Tank Capacity: Approx. 90 – 100 Liters

• Travel Speed: Up to 18 km/h

• Steering System: Articulated frame with hydrostatic steering

• Braking System: Hydraulic multi-disc brakes

---

Engine & Performance

The HW90/10 is equipped with a reliable air-cooled Deutz engine, offering consistent performance with low fuel consumption. It’s built for long hours of continuous use and is easily maintained, especially in remote or rugged conditions where simplicity matters.

• Fuel Type: Diesel

• Cooling System: Air-cooled

• Drive Type: Rear-wheel, mechanical or hydrostatic (variant dependent)

• Gradeability: Up to 25% depending on load and terrain

---

Tyre Configuration & Compaction

The HW90/10 uses a kneading compaction effect with its staggered 8-tyre layout to evenly seal asphalt surfaces and eliminate air voids. This method ensures smooth, dense layers ideal for highways, road shoulders, and parking lots.

• Tyre Arrangement: 4 front + 4 rear, overlapping configuration

• Tyre Pressure: Adjustable

• Ballast Options: Water or steel fill for weight adjustment

• Compaction Effect: High-quality sealing and bonding

---

Chassis & Mobility

Compact yet solidly built, the HW90/10 features a robust chassis and articulated steering for maneuverability in tight spaces, ideal for urban jobs or smaller construction zones.

• Frame Design: Heavy-duty welded steel

• Articulation Angle: Approx. 30 – 35°

• Turning Radius (Inside): Approx. 4.2 – 4.5 m

• Ground Clearance: Suitable for mixed-use job sites

---

Operator Station

The HW90/10 is built for practical, fatigue-free operation. The operator platform includes basic instrumentation, easy-to-use controls, and good visibility of the front and sides of the machine.

• Cab Options: Open platform with canopy or enclosed (weather-sealed)

• Seat: Adjustable suspension seat

• Controls: Manual lever controls for drive and braking

• Visibility: Wide-angle sightlines to tyres and surrounding area

• Optional: Rear-view mirrors, work lights, and sun canopy

---

Maintenance & Serviceability

Simplicity is a strength of the HW90/10. With minimal electronics and straightforward access to engine and service components, the machine is easy to maintain in the field.

• Service Points: Ground-level access

• Engine Oil Capacity: Approx. 8 Liters

• Hydraulic Oil (if equipped): Approx. 70 Liters

• Maintenance Interval: Long-life components for reduced downtime

---

Use Cases

• Asphalt surface sealing and finishing

• Road shoulder and edge compaction

• Municipal and city street maintenance

• Small road construction sites

• Base layer preparation for parking and driveways

---

Final Thoughts

The Hamm HW90/10 Roller, available through Ekin Traktors, is a reliable and affordable pneumatic tyre roller for asphalt finishing and general compaction duties. Its simple design, low maintenance demands, and effective kneading action make it a smart investment for contractors looking for dependable performance in roadwork, paving, and municipal maintenance.
