BULL HD 76 4WD Backhoe Loader

BULL HD 76 4WD Backhoe Loader – Built to Push Beyond Limits

The BULL HD 76 4WD is a robust, high-efficiency backhoe loader engineered for reliability and heavy-duty performance. Featuring four-wheel drive, advanced digging capabilities, and a powerful BS-III compliant engine, this machine delivers exceptional productivity for infrastructure, mining, and utility works.

---

Engine & Performance

Equipped with a proven Kirloskar engine, the HD 76 ensures steady power and torque output while maintaining mechanical simplicity and ease of maintenance.

• Engine Model: Kirloskar 4R1040 TC BS

• Emission Standard: BS-III

• Gross Power: 76 HP

• Maximum Torque: 300 Nm

A rugged performer suited for consistent operation under demanding job conditions.

---

Hydraulic System – High Volume, High Control

Designed for optimal flow and responsiveness, the BULL HD 76’s hydraulic system powers both loader and backhoe functions with efficiency and precision.

• Pump Flow: 113 LPM

• Hydraulic Oil Capacity (System): 120 L

Delivers robust hydraulic support for fast cycle times and reliable work output.

---

Loader Capabilities – Strong, Steady, and Efficient

The loader unit offers dependable lifting strength and a durable bucket setup, making it ideal for material movement and loading operations across multiple job sites.

• Loader Bucket Capacity (Standard): 1.1 m³

• Dump Height: 2,930 mm

• Load Over Height: 3,390 mm

• Hinge Pin Forward Reach: 420 mm

• Reach at Ground: 1,470 mm

• Rollback at Ground: 50°

• Dump Angle: 45°

• Max Reach at Full Height: 1,420 mm

• Max Lift Capacity: 1,400 kg

• Loader Arm Breakout Force: 5,251 kgf

Well-suited for bulk handling, loose material transfer, and moderate lifting tasks.

---

Backhoe Performance – Compact Yet Capable

The backhoe delivers dependable reach and breakout force, ideal for mid-range digging, trenching, and rural infrastructure projects.

• Maximum Dig Depth: 4,600 mm

• Reach (Ground Level to Rear Wheel Center): 6,810 mm

• Max Load Over Height: 3,390 mm

• Bucket Rotation: 188°

• Backhoe Bucket Capacity: 1.2 m³

• Max Lift Capacity: 1,400 kg

An excellent choice for medium-depth trenching and lifting operations with controlled precision.

---

Dimensions & Weight

Compact in form but heavy in function, the BULL HD 76 4WD is easy to transport and maneuver through confined or rural project sites.

• Max Operating Weight: 7,850 kg

A strong frame with optimal weight distribution enhances stability and performance across uneven terrain.

---

Steering & Braking

Simplified yet effective, the steering and braking systems are tuned for reliable control in tough working conditions.

• Steering Type: Power Steering

Designed for responsive directional control across all terrains, with 4WD support for added traction.

---

Tyres

Equipped with sturdy tyres capable of handling variable terrain and load profiles.

• Standard Tyres (Front): 12.5/80 – 18 – 12 PR

• Standard Tyres (Rear): 16.9 x 28 – 12 PR

Delivers balanced ground grip and load distribution.

---

Service Capacities

• Engine Oil Capacity: 12 L

• Transmission Oil Capacity: 19.5 L

• Rear Axle Oil: 17 L

• Fuel Tank Capacity: 115 L

• Coolant Capacity: 17 L

Extended service intervals and simplified maintenance access ensure long-lasting field operation with reduced downtime.

---

Applications

The BULL HD 76 4WD is well-adapted for:

• Agricultural land clearing and trenching

• Mid-scale construction and municipal works

• Sand and gravel handling

• Utility and rural road projects

A durable and cost-effective solution for operators needing power, simplicity, and reliable after-sales support.
