ACE Phantom 2WD Backhoe Loader

The ACE Phantom 2WD Backhoe Loader is a practical, fuel-efficient solution engineered for lighter terrain and general-purpose earthmoving. With a powerful 74 HP Kirloskar engine and robust hydraulic capabilities, this 2-wheel-drive variant delivers reliable performance for a wide range of construction, municipal, and agricultural applications.

Ideal for budget-conscious contractors and fleet owners, the Phantom 2WD offers the same rugged build quality and operational finesse as its 4WD counterpart, while reducing operational costs and maintenance complexity.

---

Key Specifications

• Max. Lift Capacity: 1900 Kg

• Loader Bucket Capacity: 1.0 Cum

• Backhoe Bucket Capacity: 0.24 Cum

• Max. Reach at Full Height: 1220 mm

• Hydraulic Oil Capacity: 80 Ltr

• Max Operating Weight: 8040 Kg

---

Engine

• Model: KIRLOSKAR 4R1190NA1

• Emission Compliance: BS-IV

• Type: Inline, Naturally Aspirated, Water-Cooled

• Gross Power: 74 HP

• Maximum Torque: 300 NM

Powered by a BS-IV compliant inline water-cooled engine, the Phantom 2WD offers strong low-end torque and smooth operation — ideal for long shifts in mid-load excavation, utility repair, or site preparation jobs. The naturally aspirated design ensures long engine life and simplified maintenance.

---

Loader Performance & Dimensions

• Dump Height: 2760 mm

• Load Over Height: 3340 mm

• Hinge Pin Height: 3630 mm

• Reach at Ground: 1770 mm

• Rollback at Ground: 44°

• Dump Angle: 45°

• Standard Bucket Capacity: 1.0 Cum

• Loader Arm Breakout Force: 4950 Kgf

Despite its 2WD configuration, the loader setup delivers solid lifting capacity and breakout force, allowing it to efficiently handle soil, sand, bricks, and gravel on stable ground.

---

Backhoe Performance & Dimensions

• Maximum Digging Depth: 4250 mm

• Max Working Height: 5470 mm

• Max Load Over Height: 3790 mm

• Bucket Rotation: 175°

• Dipper Tear Out Force: 4000 Kgf

• Bucket Capacity: 0.24 Cum

Engineered for precision and stability, the backhoe arm’s 175° bucket rotation and 4.25 m dig depth make it ideal for trenching, cable laying, and foundation digging.

---

Hydraulic System

• Pump Flow: 118 LPM

• Relief Pressure: 210 Bar

• Hydraulic System Oil Capacity: 80 Ltr

This high-pressure hydraulic system enables smooth and responsive performance for simultaneous loader and backhoe operations. It’s optimized for lower engine strain, helping extend equipment life.

---

Overall Dimensions & Weight

• Operating Weight: 8040 Kg

• Width Over Bucket: 2500 mm

• Wheelbase: 2180 mm

• Ground Clearance: 350 mm

• Cabin Height: 2900 mm

The machine’s compact but sturdy build ensures balanced operation, stable maneuvering on solid terrain, and ease of transport between job sites.

---

Powertrain

• Transmission: Synchro-shuttle with torque converter

• Rear Axle: Rigid axle with CARRARO planetary drive

• Front Axle: Centrally pivoted steer axle

The synchro-shuttle transmission offers smoother directional shifts, essential for loader work in confined spaces or repetitive cycle operations. With a proven torque converter setup, the drive system optimizes gear power delivery and operator control.

---

Steering & Brakes

• Steering Type: Hydrostatic

• Service Brakes: Hydraulically Actuated Disc Brakes

• Parking Brakes: Mechanically Actuated Disc Brakes

Reliable steering and braking systems ensure precision handling and on-site safety. Ideal for operators working in congested environments or semi-urban projects.

---

Service Capacities

• Engine Oil: 11.5 Ltr

• Rear Axle Oil: 3 Ltr

• Fuel Tank: 150 Ltr

• Coolant: Water-Cooled

• Hydraulic Oil: 80 Ltr

High-capacity tanks reduce the need for frequent servicing and fuel stops — a key advantage for contractors working extended hours or in remote areas.

---

Tyres

• Front Tyres: 9.00 x 16 – 16 PR

• Rear Tyres: 16.90 – 28 – 12 PR

The tyre profile supports balanced traction with reduced soil disturbance. Best suited for firm terrain and controlled job sites.

---

Electrical System

• Battery: 12 V

Provides stable power for engine ignition and optional electrical accessories like cabin fans, work lights, or telematics.

---

Use Case Scenarios

• Urban Utility Work: Cable trenching, pipeline laying, stormwater drains

• Agriculture & Irrigation Projects: Canal work, fencing, and field preparation

• Municipal Operations: Roadside maintenance, cleaning, pit digging

• Construction Support: Material shifting, compact excavation, loader use

• Rental Applications: Low-maintenance, easy-to-operate machine for general use

---

Why Choose the ACE Phantom 2WD?

For contractors seeking a cost-effective, reliable, and fuel-efficient backhoe loader, the ACE Phantom 2WD strikes the right balance. It delivers ACE’s trusted durability and hydraulic performance in a simpler, 2-wheel-drive package — ideal for low to medium complexity projects.

Now available through Ekin Traktors. Contact us to request a quote, schedule a machine inspection, or explore finance options.
